WD55T Joinery System

Brand: Akpa

WD55T Joinery System is a heat insulated aluminum door and window system.

Please click on "Offer Request" button below to send your offer and detailed information request to the company for the WD55T Joinery System product.

All building types


• Heat insulated door and window systems
• Body depth: 55 mm
• Profile wall thickness: 1.5 mm - 2 mm
• Narrow and wide forehead alternative profiles
• Glass bead support between 4 mm and 30 mm
• Fireproof heat barrier alternatives
• Press corner and connection wedges
• Normal, double axis, transom, sliding-transom, outward opening, folding or crash opening options
• Profile production with QUALICOAT certificate in all RAL colors and QUALANOD certified in anodized options.
• EPDM air, water and dust sealing wicks
• Rosenheim heat test report
• Uw = 2,9W / (m2.K)

EN 12207 Class 4 600 Pa
EN 12208 Class 9A 600 Pa
EN 12210 Class C3 1200 Pa
TS EN ISO 717-1 37,7 Db
